Glass Universal Sensor for Temperature, Brightness, Humidity, Motion & IR Reception; in White The LCN-GUS68W is a specialized universal sensor designed for use in 68mm switch boxes. It offers the same functions as the other models in the LCN-GT series and is suitable for all LCN modules from firmware version 1702 (February 2013). Application Areas This sensor is ideal for integration into modern smart home systems, where it can be used to monitor and control room climate and lighting. It contributes to energy efficiency and comfort in residential and commercial spaces. Technical Data Mounting: For ceiling or wall mounting (switch box 68mm) Dimensions: 90mm x 90mm x 18mm (W x H x D) Protection class housing: IP20 Protection class sensor: IP20

Glass Universal Sensor for Temperature, Brightness, Humidity, Motion & IR Reception; in Champagne The LCN-GUS68C is an elegant universal sensor designed for use in 68mm switch boxes. It offers comprehensive functions for measuring temperature, brightness, humidity, and motion and is compatible with all LCN modules from firmware version 1702 (February 2013). Application Areas This sensor is excellent for modern building automation systems, where it can be used to monitor and control lighting and room climate. It optimizes energy consumption and enhances comfort in residential and commercial spaces. Technical Data Mounting: For ceiling or wall mounting (switch box 68mm) Dimensions: 90mm x 90mm x 18mm (W x H x D) Protection class housing: IP20 Protection class sensor: IP20

Glass Universal Sensor for Temperature, Brightness, Humidity, Motion & IR Reception; in White The LCN-GUSW is a highly developed universal sensor that offers the same functions as the LCN-GUSB but in an elegant white design. It measures temperature, brightness, humidity, and motion and is suitable for all LCN modules from firmware version 1702 (February 2013). Application Areas Ideal for use in residential and commercial spaces where precise monitoring of environmental conditions is required. The sensor can be used for the automatic control of heating and lighting systems to optimize energy consumption. Technical Data Mounting: For ceiling or wall mounting (lamp outlet box 35mm) Dimensions: 60mm x 60mm x 30mm (W x H x D) Protection class housing: IP20 Protection class sensor: IP20

Issendorff LCN-PMIflex The LCN-PMIflex is an innovative presence and motion detector with a flexibly adjustable lens, designed for indoor use. It is used for connection to intelligent LCN modules and operates on the PIR principle (Passive Infrared) to detect movements by sensing changes in thermal radiation. The sensor is ideal for automating lighting in hallways, offices, or restrooms and can also take on alarm functions in building monitoring. It triggers the ON command once when it detects movement. For short-term detection, the OFF command is executed after four seconds, while for longer detection, the OFF command occurs eight seconds after the last movement. The LCN-PMIflex also automatically sends status messages without parameterization and allows for easy installation through its integrated ball head, which enables precise adjustment of the detection direction. Application Areas The LCN-PMIflex is excellent for switching lighting and other consumers upon detecting movement and presence. When multiple sensors are connected to one module, each motion detector must act on a different button, which can be set using the DIP switch.

Glas-Universalsensor für Temperatur, Helligkeit, Feuchte, Bewegung & IR-Empfang; in Champagner Der LCN-GUS ist ein vielseitiger Universalsensor, der speziell für die Erfassung von Temperatur, Helligkeit, Feuchtigkeit und Bewegung entwickelt wurde. Er integriert zudem einen IR-Empfänger und ist im eleganten Design der LCN-GT-Serie gehalten. Dieser Sensor ist ideal für den Einsatz in modernen Smart Home-Systemen und kann mit allen LCN-Modulen ab Firmware-Version 1702 (Februar 2013) verwendet werden. Anwendungsbeispiele Automatische Anpassung der Raumbeleuchtung basierend auf der Helligkeit. Temperaturüberwachung in Wohn- und Arbeitsräumen zur Optimierung des Raumklimas. Bewegungserkennung zur Aktivierung von Alarmanlagen oder Beleuchtung. Technische Daten Montage: Zur Decken- oder Wandmontage (Lampenauslassdose 35mm) Abmessungen: 60mm x 60mm x 30mm (B x H x T) Schutzart Gehäuse: IP20 Schutzart Sensor: IP20

Passive Infrared Presence/Motion Detector The LCN-PMI is a state-of-the-art passive infrared presence and motion detector designed for indoor use. It detects movements by sensing changes in the thermal radiation of objects within its detection range and is excellent for automating lighting systems in residential and commercial spaces. The connection is made via the I terminal of an LCN module. The lead can be extended by up to two LCN-IV up to 50 meters, allowing for flexible installation. Technical Data Mounting: Screw fastening to a junction box Ø 35mm Dimensions: Ø 45mm x 25mm Protection class: IP20 The LCN-PMI is ideal for integration into modern building automation systems.

Issendorff LCN-KUS55W in weiß Der LCN-KUS55W ist ein multifunktionaler Präsenzmelder, der als Infrarot-, Licht-, Feuchte- und Temperatursensor für den Innenbereich konzipiert wurde. Er gehört zur LCN-MT4 (System 55) Serie und ist für den I-Anschluss eines LCN-Busmoduls ab Firmware 1E05 (Mai 2020) geeignet. Der Sensor ist kompatibel mit den LCN-G55 Rahmen sowie handelsüblichen System 55mm Rahmen. Technische Details Temperatursensor: Hochpräzise Messwerte mit integriertem Prozessor Lichtsensor: Erfassung von Helligkeit im Bereich von 1 bis 100.000 Lux Präsenz-/Bewegungsmelder: Erkennt Bewegungen durch Wärmestrahlung IR-Empfänger: Verarbeitung von Signalen der LCN-Fernbedienungen Anwendungsgebiete Integrierte Klima- und Raumluftregelung basierend auf Temperatur und Feuchtigkeit Helligkeitssensor für Konstantlichtregelungen Bewegungs- und Präsenzsensor zur Steuerung von Beleuchtung IR-Empfänger zur Steuerung des LCN-Systems mit einem IR-Handsender

Glass universal sensor for temperature, brightness, humidity, motion & IR reception; in black The LCN-GUS68B is a versatile universal sensor specifically designed for integration into 68mm switch boxes. It allows for precise measurement of temperature, brightness, humidity, as well as motion detection and IR reception. This product is ideal for modern building automation systems and can be used in conjunction with all LCN modules from firmware version 1702 (February 2013). Application Examples Automatic control of lighting based on room brightness. Regulation of room temperature through precise temperature measurement. Motion detection for activating alarm systems or controlling lights. Technical Data Installation: For ceiling or wall mounting (switch box 68mm) Dimensions: 90mm x 90mm x 18mm (W x H x D) Protection class housing: IP20 Protection class sensor: IP20

Issendorff LCN-KUS55B in schwarz Der LCN-KUS55B ist ein Präsenzmelder, der als Infrarot-, Licht-, Feuchte- und Temperatursensor für den Innenbereich dient. Er ist Teil der LCN-MT4 (System 55) Serie und für den I-Anschluss eines LCN-Busmoduls ab Firmware 1E05 (Mai 2020) geeignet. Der Sensor passt in die LCN-G55 Rahmen oder handelsübliche System 55mm Rahmen. Technische Details Temperatursensor: Liefert hochpräzise Messwerte Lichtsensor: Erfasst Helligkeit von 1 bis 100.000 Lux Bewegungsmelder: Erkennt Bewegungen durch Wärmestrahlung IR-Empfänger: Verarbeitet Signale von LCN-Fernbedienungen Anwendungsgebiete Klima- und Raumluftregelung basierend auf Temperatur und Feuchtigkeit Helligkeitssensor für Konstantlichtregelungen Bewegungs- und Präsenzsensor zur Steuerung von Beleuchtung IR-Empfänger zur Steuerung des LCN-Systems mit einem IR-Handsender

Glass Universal Sensor for Temperature, Brightness, Humidity, Motion & IR Reception; in Black The LCN-GUSB is a versatile universal sensor specifically designed for precise measurement of temperature, brightness, humidity, and motion. It features the elegant design of the LCN-GT series and is suitable for use with all LCN modules from firmware version 1702 (February 2013). Application Areas The LCN-GUSB is used in modern smart home systems, where it can be employed for the automatic control of heating, lighting, and air conditioning. By capturing environmental data, it enables intelligent adjustments of room conditions, enhancing comfort while saving energy. Technical Data Mounting: For ceiling or wall mounting (lamp outlet box 35mm) Dimensions: 60mm x 60mm x 30mm (W x H x D) Protection class housing: IP20 Protection class sensor: IP20
